Fig. 1.
Technische Daten / Specifications / Spécifications / Specifiche / Datos técnicos /
Technische gegevens / Tekniske data / Tekniska data / Technická data / Dane techniczne
Item number
Connections
Input
Output
Average active efficiency
Efficiency at low load (10 %)
No-load power consumption
Adapter plugs
Dimensions
Cable length
Weight
Polarity of DC connectors
Protection level /
Protection class
Colour
Verwendete Symbole / Symbols used / Symboles utilisés / Simboli utilizzati /
Símbolos utilizados / Gebruikte symbolen / Brugte symboler / Använda symboler /
Použité symboly / Stosowane symbole
For indoor use only
Alternating current
Direct current
Class II equipment
Polarity of d.c. power connector
REV2024-08-14
Änderungen und Irrtümer vorbehalten.
V1.0fw
Euro plug (type C, CEE 7/16), DC plug 5.5 x 2.1 mm
100-240 V
5.0 V
6.0 V
7.5 V
9.0 V
12.0 V
13.5 V
15.0 V
Micro-USB plug, USB Mini-B plug, Screw terminal connector,
USB-C™ plug, DC plug 3.0 x 1.1 mm, DC plug 3.5 x 1.35 mm,
DC plug 2.5 x 0.7 mm, DC plug 4.0 x 1.7 mm, DC plug 4.8 x 1.7 mm,
DC plug 5.5 x 2.5 mm, USB-A socket
76.1 x 43.5 x 49.2 mm
positive
- 1 -
38112 Braunschweig | Germany | cs@wentronic.com
74436
, 50/60 Hz, 1.0 A
, 2.4 A, 12.0 W max. or
, 2.4 A, 14.4 W max. or
, 2.4 A, 18.0 W max. or
, 2.4 A, 21.6 W max. or
, 2.4 A, 28.8 W max. or
, 2.4 A, 32.4 W max. or
, 2.4 A, 36.0 W max.
82.46 %
81.41%
0.05 W
1.8 m
126.5 g
IP20 / II
black
IEC 60417- 5957
IEC 60417- 5032
IEC 60417- 5031
IEC 60417- 5172
IEC 60417- 5926
Goobay® by Wentronic GmbH | Pillmannstraße 12
74436
