II
. ASSEMBLY
Selecting Mode
Select Mode
Applications & work material
Wood
Drill Driver
Drilling
Metal
Wood screw
Metal screw
Driving
Impact
Wood screw
Metal screw
Tech screw
Plastic anchor
Coach screw (Lag bolt)
Fastening
Bolt nut
Concrete anchor
Select appropriate mode (Drill driver mode or
Impact mode) sliding the Mode selector switch.
Note: When selecting the mode, disconnect bat-
tery pack from tool or place Reversing
Attaching or Detaching Original Options and Accessories
Keep the body above freezing point (0°C 32°F) when attach or detach original options and accessories
to the square drive on the body. The cushion rubber in the square drive to push up the ball may get
hard under freezing point. This requires extra force in detaching and attaching accessories.
Original Options
13mm(1/2") keyless
EY9X003E
Quick change chuck for
6.35mm (1/4")
Hexagonal shank bits
(Quick release type)
EY9HX110E
Drill driver mode
with clutch function
—
—
7
Accessories in the market
Wood/metal
Hole saw
(+)(-) head
Torx head
(+)(-) head
Torx head
Hexagonal socket
lever in the center position.(switch lock)
Do not operate Mode selector switch until
the rotation of the spindle comes to a com-
plete stop.
Impact mode
