Luchtgestuurde hydraulische voetpomp
Refer to the Specification chart above for details of oil port thread size,
usable oil capacity, and more.
The operation of the Unit is as follows:
1. Connect the hose of the Air Hydraulic pump to the hydraulic coupling
on the selected tool.
2. Connect the air supply line to the Air Hydraulic pump. The air supply is
5- 10 CFM at 100 PSI to obtain proper operating characteristics. In addition,
the airline should be equipped with an air line filter.
Foot Pedal operate pumps:
a. Depress the "Pump" end of the pedal will pump hydraulic oil into
the system.
b. Stop depressing the "Pump" or "Release" end will stop and hold
the pressure.
c. Depress the "Release" end of the pedal will release the pressure in
the system.
OPERATION
- 7 -
