Overzicht van foutcodes die op het display worden weergegeven

Code F

Short description

F01

hydraulic oil sensor

F02

material flow sensor

F03

brake pressure sensor

F04

engine cooling sensor

F05

engine oil level sensor

F06

engine air filter sensor

F07

drive pump sensor

F08

Engine CAN BUS error

F11

joystick

F12

speed potentiometer

F13

travel mode switch

F14

material flow mode switch

F15

material flow direction switch

F16

screed height switch

F19

screed vibration switch

F21

horn button

F22

engine start switch

F23

deadman button

F24

extension left in switch

F25

extension left out switch

F26

extension right in switch

F27

extension right out switch

F28

joystick forward switch

F29

joystick reverse switch

F30

joystick neutral switch

F31

drive pump forward

F32

drive pump reverse

F33

drive pump safety

F34

brake release output

F35

brake release safety

F36

material flow valve forward

F37

material flow valve reverse

F38

material flow safety

F39

floating valve

F40

floating safety

De teksten worden alleen in de originele taalversie verstrekt of als de vertaling van het origineel naar de Engelse taalversie.

F80W

Causes and troubleshooting

short circuit to ground detected – check wiring (X41, RD 141, WH 227)

short circuit to ground detected – check wiring (X43, RD 143, WH 229)

short circuit to ground detected – check wiring (X42, RD 142, WH 228)

short circuit to battery detected – check wiring (X18:5, X35)

short circuit to battery detected – check wiring (X17:4)

short circuit to battery detected – check wiring (X18:3)

short circuit to ground or battery or no connection detected – check wiring (X38,

WH 214, WH 217, WH 222)

Check CAN communication (A9:47,A9:48, X9:3, X9:4, X50, X51, X52, X53, X55,

X34:62, X34:63, A2:162, A2:163)

most frequent cause: joystick not calibrated; error param 1 to 6: redundancy failu-

re; error param 7: not calibrated; error param 8: error on main channel; error param

9: error on redundant channel (X36)

most frequent cause: error on main channel; error param 1 to 6: redundancy failure;

error param 8: error on main channel; error param 9: error on redundant channel

short circuit to ground detected – check wiring (X53, RD 153, WH 243)

short circuit to ground detected – check wiring (X52, RD 152, WH 242)

short circuit to ground detected – check wiring (X51, RD 151, WH 240, WH 241)

short circuit to ground detected – check wiring (X48, RD 148, WH 236, WH 237)

short circuit to ground detected – check wiring (X49, RD 149, WH 238)

short circuit to ground detected – check wiring (X45, RD 145, WH 231)

short circuit to ground detected – check wiring (137)

short circuit to ground detected – check wiring (X44, RD 144, WH 230)

short circuit to ground detected – check wiring (X46, RD 146, WH 233)

short circuit to ground detected – check wiring (X46, RD 146, WH 232)

short circuit to ground detected – check wiring (X47, RD 147, WH 234)

short circuit to ground detected – check wiring (X47, RD 147, WH 235)

short circuit to ground detected – check wiring (X36)
