Indeling van MIDI-gegevens
Als u al vertrouwd bent met MIDI of een computer gebruikt voor het besturen van uw muzieksysteem via op de computer gegenereerde
MIDI-berichten, kunt u de gegevens in dit gedeelte gebruiken voor het besturen van de CLP-240/230.
1. NOTE ON/OFF
Data format: [9nH] -> [kk] -> [vv]
9nH = Note ON/OFF event (n = channel number)
kk =
Note number (Transmit: 09H ~ 78H = A-2 ~ C8 /
Receive: 00H ~ 7FH = C-2 ~ G8)*
vv =
Velocity (Key ON = 01H ~ 7FH, Key OFF = 00H)
Data format: [8nH] -> [kk] -> [vv] (reception only)
8nH = Note OFF event (n = channel number)
kk =
Note number: 00H ~ 7FH = C-2 ~ G8
vv =
Velocity
* If received value exceeds the supported range for the
selected voice, the note is adjusted by the necessary num-
ber of octaves.
2. CONTROL CHANGE
Data format: [BnH] -> [cc] -> [vv]
BnH = Control change (n = channel number)
cc =
Control number
vv =
Data Range
(1) Bank Select
ccH
Parameter
00H
Bank Select MSB
20H
Bank Select LSB
Bank selection processing does not occur until receipt of
next Program Change message.
(2) Modulation (reception only)
ccH
Parameter
01H
Modulation
(3) Main Volume (reception only)
ccH
Parameter
07H
Volume MSB
(4) Panpot (reception only)
ccH
Parameter
0AH
Panpot
(5) Expression
ccH
Parameter
0BH
Expression MSB
(6) Damper
ccH
Parameter
40H
Damper MSB
(7) Sostenuto
ccH
Parameter
42H
Sostenuto
(8) Soft Pedal
ccH
Parameter
43H
Soft Pedal
(9) Effect1 Depth (Reverb Send Level)
ccH
Parameter
5BH
Effect1 Depth
Adjusts the reverb send level.
(10) Effect4 Depth (Variation Effect Send Level)
ccH
Parameter
5EH
Effect4 Depth
80
CLP-240/230 Gebruikershandleiding
Data Range (vvH)
00H: Normal
00H...7FH
Data Range (vvH)
00H-7FH
Data Range (vvH)
00H...7FH
Data Range (vvH)
00H-7FH
Data Range (vvH)
00H...7FH
Data Range (vvH)
00H...7FH
Data Range (vvH)
00H-3FH:off, 40H-7FH:on
Data Range (vvH)
00H-3FH:off, 40H-7FH:on
Data Range (vvH)
00H...7FH
Data Range (vvH)
00H...7FH
(11) RPN
ccH
Parameter
65H
RPN MSB
64H
RPN LSB
06H
Data Entry MSB
38H
Data Entry LSB
3. MODE MESSAGES
Data format: [BnH] -> [cc] -> [vv]
BnH = Control event (n = channel number)
cc =
Control number
vv =
Data Range
(1) All Sound Off
ccH
Parameter
78H
All Sound Off
Switches off all sound from the channel. Does not reset Note
On and Hold On conditions established by Channel Messages.
(2) Reset All Controllers
ccH
Parameter
79H
Reset All Controllers
Resets controllers as follows.
Controller
Expression
Damper Pedal
Sostenuto
Soft Pedal
(3) Local Control (reception only)
ccH
Parameter
7AH
Local Control
(4) All Notes Off
ccH
Parameter
7BH
All Notes Off
Switches OFF all the notes that are currently ON on the spec-
ified channel. Any notes being held by the damper or soste-
nuto pedal will continue to sound until the pedal is released.
(5) Omni Off (reception only)
ccH
Parameter
7CH
Omni Off
Same processing as for All Notes Off.
(6) Omni On (reception only)
ccH
Parameter
7DH
Omni On
Same processing as for All Notes Off.
(7) Mono (reception only)
ccH
Parameter
7EH
Mono
Same processing as for All Sound Off.
(8) Poly (reception only)
ccH
Parameter
7FH
Poly
Same processing as for All Sound Off.
• When control change reception is turned OFF in the Function
mode, control change data will not be transmitted or received.
• Local on/off, OMNI on/off are not transmitted. (The appropriate
note off number is supplied with "All Note Off" transmission).
Data Range (vvH)
Coarse Tune 02H,
Fine Tune 01H,
Pitch Bend Range 00H
Data Range (vvH)
00H
Data Range (vvH)
00H
Value
127 (max)
0 (off)
0 (off)
0 (off)
Data Range (vvH)
00H (off), 7FH (on)
Data Range (vvH)
00H
Data Range (vvH)
00H
Data Range (vvH)
00H
Data Range (vvH)
00H
Data Range (vvH)
00H
