Explanation of
Various wiring variants can be connected to the multifunction current interface.
the multifunc-
However, these cannot be operated simultaneously. For example, if an S0 meter
tion current in-
is connected to the multifunction current interface, it is not possible to connect
terface
a signal contact for the surge protection device (or vice versa).
Pin 1 = measurement input: max. 20 mA, 100 Ohm measurement resistor (load
impedance)
Pin 2 = max. short circuit current 15 mA, max. open-circuit voltage 16 V DC or
GND
Wiring diagram variant 1: Signal contact for surge protective device
Depending on the setting in the Basic menu (Signal Input submenu), the DC SPD
option (surge protective device) either outputs a warning or an error on the dis-
play. Further information on the DC SPD option can be found in the Installation
Instructions.
Wiring diagram variant 2: S0 meter
A meter for recording the self-consumption of each S0 can be connected dir-
ectly to the inverter. This S0 meter can be positioned directly at the feed-in point
or in the consumption branch.
IMPORTANT! In order to connect an S0 meter to the inverter, it may be neces-
sary to update the inverter firmware.
The S0 meter must comply with the IEC62053-31 Class B standard
Recommended max. pulse rate of the S0 meter:
PV output kWp [kW]
30
20
10
≤ 5.5
With this meter, dynamic power reduction can be performed in two ways:
-
-
Fail-Safe
In the Fronius Solar Net ring (a combination of several inverters), the Fail-Safe
function prevents inadmissible feeding of the connected inverters in the start-up
Dynamic power reduction by means of inverter
For more information see chapter
verter
on page
16
Dynamic power reduction by means of the Fronius Datamanager 2.0
for more info see:
manuals.fronius.com/html/4204260191/
#0_m_0000017472
Max. pulse rate per kWp
1000
2000
5000
10000
Dynamic power reduction by means of in-
