Connect inverter with Fronius Datamanager 2.0 or Fronius Datamanager Box 2.0 to
1
the Fronius Solar Net
When networking several inverters together in Fronius Solar Net:
2
Set the Fronius Solar Net master / slave switch on the Fronius Datamanager 2.0 plug-
in card correctly
-
One inverter with Fronius Datamanager 2.0 = master
-
All other inverters with Fronius Datamanager 2.0 = slave (the LEDs on the Fronius
Datamanager 2.0 plug-in cards are not illuminated)
Switch the device to Service mode.
3
-
Activate the WiFi Access Point via the Setup menu on the inverter.
S t a n d b y
W i F i A c c e s s P o i n t
D A T C O M
U S B
C l o c k
The inverter establishes the WLAN access point. The WLAN access point remains open
for 1 hour.
Installation using the Solar.web App
Download the Fronius Solar.web
4
App.
Run the Fronius Solar.web App.
5
The Setup wizard start page is displayed.
Installation using a web browser
Connect the end device to the WLAN
4
access point
SSID = Fronius_240.xxxxx (5-8 dig-
its)
-
Search for a network with the
name "Fronius_240.xxxxx"
-
Establish a connection to this
network.
-
Enter the password 12345678.
(Alternatively, connect the end device
and inverter using an Ethernet cable.)
Enter the following in the browser:
5
http://datamanager
or
192.168.250.181 (IP address for
WLAN connection)
or
169.254.0.180 (IP address for LAN
connection).
17
