4.4 Pre-set Flip back armrests / Single post removable
armrests
Armrest height (figure 4.16)
1. Loosen (A) by one turn.
2. Adjust (B) to the desired position.
3. Tighten (A).
Ensure that the arms are supported well, without the
shoulders being pushed upwards.
Armrest depth (figure 4.17)
1. Loosen (A) by one turn.
2. Adjust (B) to the desired position.
3. Tighten (A).
Position the Flip back armrest further back in order to obtain
more space for side wards transfers. Position the armrest
further to the front to obtain more support for forward
transfers.
Armrest pad depth (figure 4.18)
1. Loosen (A) by one turn.
2. Adjust (B) to the desired position.
3. Tighten (A).
12
1
B
A
2
A
2
1
2
B
2
A
Sedeo Pro | Rev.F | English
Fig. 4.16
Fig. 4.17
B
M5
M5
Fig. 4.18
1
M5
3
M5
