CHARACTERISTICS OF TOOL
Pneumatic grinder is powered with a stream of compressed air at the appropriate pressure. By using the and cutting and grinding wheels it is
possible to cut and grind various materials. The device is designed for use only in households and can not be used professionally, ie. In the
workplace and for work to earn money. The tool is not designed for continuous operation. Recommended mode of operation is casual work during
5 minutes, then you should wait for 30 minutes, to cool the tool. Correct, reliable, and safe operation of the tool is dependent on its proper use,
therefore:
Prior to working with the tool, you should read all the instruction and keep it around.
For any damage or injuries caused by the tool misuse, failure to comply with safety regulations and instructions in this manual, the supplier is not
responsible. The tool misuse causes also the loss of user rights to the guarantee and warranty. as it would be a non-compliance with the contract.
EQUIPMENT
The grinder is equipped with a coupling to attach it to the pneumatic system. The device is also equipped with the keys, which allow you to attach
an accessory in the holder
TECHNICAL DATA
Parameter
Catalog number
Weight
The diameter of the air connection (PT)
The diameter of the air inlet hose (internal)
Rotations
Diameter of tool holder
Maximum operation pressure:
Required air fl ow (at 6.2 bar)
Sound pressure (ENISO 15744)
Sound power (ISO 15744)
Vibration (EN 28662-1)
GENERAL SAFETY CONDITIONS
WARNING! When you are working with a pneumatic tool, we recommend that you always comply with the basic principles of occupational safety,
including the principles presented below, in order to reduce the risk of fi re, electric shock and to prevent injuries.
Prior to working with the tool, you should read all the instruction and keep it around.
ATTENTION! Read all the instructions below. Failure to comply with them can lead to electrical shock, fi re or personal injury. The concept of
"pneumatic tool", which is used in the instructions, refers to all tools, which are driven by a stream of air compressed at the right pressure.
COMPLY WITH THE FOLLOWING INSTRUCTIONS
General safety conditions
Before starting the installation, work, repair, maintenance and changing of accessories, or when you are working near pneumatic tool, because
of many risks, you should read and understand the safety instructions. if the above mentioned steps are not taken, it may result in serious injury.
Installation, adjustment and installation of pneumatic tools may be performed only by qualifi ed and trained staff . Do not modify the pneumatic tool.
O R I G I N A L
12
EN
Unit
[kg]
[''] / [mm]
[''] / [mm]
[min
]
-1
[mm]
[MPa]
[l/min]
[dB(A)]
[dB(A)]
[m/s
]
2
I N S T R U C T I O N S
Value
81108
0.60
1/4 / 6.3
3/8 / 10
22,000
6
0.63
127
88.0 ± 3.0
99.0 ± 3.0
2.9 ± 1.5
