EN
If you use any additional handles or supporting racks, you should make sure, that the tool is mounted correctly and securely.
You should adopt an appropriate posture to counteract the normal or unexpected movement of the tool, caused by its torque.
Be careful of your work surroundings, the grinder machine can easily cut through something.
Do not use any grinding wheels and tools designed for grinding the their surface side, for cutting.
Do not use any cutting wheels or wheels for milling.
Self-mounting grinding wheels should be concentric located on the grinder pad.
When you turn off the grinder, your should wait with its stacking, until a complete stop to the rotating tool.
Before the installation of additional equipment, your should make sure the maximum speed of the equipment is higher than the speed of the grinder.
Do not use any equipment with handles of other dimensions than those specifi ed in the instructions. Insert tool must be fi rmly and securely mounted
in the tool holder. Do not use reduction rings and sleeves, in order to match the diameter of the tool spindle and grinding wheel.
Abrasive element of the getting wheel should be stored and used in accordance with its manufacturer's instructions. Do not use damaged
equipment. Equipment with any faults must be replaced immediately to new and effi cient. Check the status of the spindle and tool holders for wear
or damage.
Do not operate the grinder in a place with a high risk of explosion. The sparks, which are produced during operation, can cause a fi re.
After mounting the grinding wheel you should run it for about 30 seconds in a safe position. Immediately stop the device, if you observe a large
vibration or other defects in the grinder behavior.
Any irregularities must be removed before the next launch of the grinder.
You should make sure that the grinding speed is not greater than the speed which is specifi ed on the rating plate.
During processing of certain materials, poisonous or combustible dusts and fumes can be created. Work in well ventilated areas and use personal
protective equipment.
When you are selecting safeguard measures you should take into account the type of workpiece.
You should make sure, that sparks and debris created during operation do not cause any hazards.
Use personal protective equipment such as gloves, apron, helmet.
In the case of dropped tools with a mounted grinding wheel, before subsequent switching it on, you should carefully check the condition of the
grinding wheel.
OPERATING OF THE TOOL
Before each use, you should check that none of the components of the product is damaged. If you notice any damage, you should replace the
element immediately with new one, undamaged system component.
Before each use of the the pneumatic system, you should dry the moisture condensed inside the tool, compressor and pipes.
Connecting the tool to pneumatic system
The fi gure shows the recommended connection of tool to the pneumatic system. Presented method will ensure the most effi cient use of tool, and
also it will extend the service life of the tool.
Let a few drops of oil with viscosity SAE 10 to the air intake.
To the thread of air inlet you should tightly and fi rmly screw the appropriate tip allowing for the connection of air supply hose. (II)
On the tool driver you should mount an appropriate tipl. When you work with pneumatic tools you should use only equipment designed to
work with the impact tools.
Set the desired direction of rotation. The letter F means, that the rotation is clockwise, letter R that the rotation is counter-clockwise.
Where it is possible you can adjust the pressure (torque).
Connect the tool to an air system by using the hose with an inner diameter of 10 mm / 3/8 ". Make sure, that the strength of the hose is at least
1.38 MPa. (III)
Start the tool for a few seconds, making sure that it does not issue any suspicious sounds or vibrations.
Installation and replacement of equipment (IV)
Make sure that the maximum speed of the equipment is higher than the speed of the grinder. You should follow the recommendations of
manufacturers of grinding wheels in relation to their speed and the mandrel length, which should be mounted in the spindle.
Grab the spindle and unscrew the mounting nut until the handle will allow for mounting of the equipment.
Mount a piece of equipment, so at least 10 mm of the mandrel is located inside the spindle.
By using keys, tightly and fi rmly screw the nut which is locking the spindle.
O R I G I N A L
I N S T R U C T I O N S
15
