2
Electrical connection
The installation and assembly may only be carried out by an electrical specialist (VDE
0105).
The maximum permitted voltage is 230 V. The mains socket must be installed as close
as possible to the device and interlocked with the filter pump. Thus, the mains socket
may carry voltage only when the filter pump is operating.
During work on the electrical system, the damp environment carries an increased risk
of electrical shock. At the same time, an incorrectly implemented installation of the
electrical protective conductor may lead to electrical shock, e.g. by way of oxidation or
cable breakage.
Observe the VDE regulations as well as those of the power supply company. Set up the
swimming pool and the associated safety zones in accordance with DIN VDE 0100-702.
Before carrying out work on the electrical system, take the following precautions:
• Disconnect the system from the power supply.
• Apply warning sign: "Do not switch on! We are working on the system."
• Check that no voltage is present.
Check the electrical system regularly to ensure that it is in a proper state.
WARNING
Risk of electrical shock caused by incorrect connection!
Observe the VDE regulations as well as those of the power supply
company.
Install pumps for the swimming pool and the associated safety
zones in accordance with DIN VDE 0100-702.
Install a separation mechanism designed to interrupt the voltage
supply with a min. 3 mm contact opening per terminal.
WARNING
Protect the power circuit with a residual current device, nominal
residual current IΔN ≤ 30 mA.
Only use appropriate cable types in accordance with regional
regulations.
Adapt the minimum cross-section of the cables to the motor
performance and the cable length.
Should there be potential for dangerous situations, install an
48
