c) Copying Model Memory „MDL COPY"
For simple programming of the system you have the option of copying data from one currently activated model memo-
ry to another. This way the factory parameters can be left in a model memory and individual changes can be made to
the copied model memory without the factory settings being lost.
To copy the data from one model memory into another, proceed as follows:
• Call the system settings menu.
• Select the menu item „MDL COPY" with the buttons „UP" or
„DOWN".
• Activate the menu item with the button „SELECT".
The display shows the currently called model memory, the
modulation type and the model type and the model name.
The bottom line shows the target memory „MODEL 1....
MODEL 10".
• Pushing the buttons „INC (+)" and „DEC (-)" sets the desired
target memory into which the data are copied.
• Push the button „SELECT" to start copying. The display of the
target memory is briefly hidden and then appears again.
• Push the buttons „UP" and „DOWN" at the same time to re-
turn to the overview of the system setting menu.
• Select the target memory and check if copying has been per-
formed correctly.
90
All manuals and user guides at all-guides.com
Figure 25
