Note:
* = not included in the scope of delivery!
1. Turn the quick-release chuck (2) anti-clockwise until
the chuck opening (1) is large enough to insert the
tool attachment*.
2. Insert the tool attachment* into the quick-release
chuck (2) as far as possible.
3. Turn the quick-release chuck (2) clockwise to clamp
the tool attachment* tight.
4. To remove the tool attachment* again, untwist the
quick-release chuck (2) and remove the tool attach-
ment*.
8.4
Test run
Note:
Before the first work and after each tool attachment
change, carry out a test run without load. Switch off the
product immediately if the tool attachment runs out of
round, there is considerable vibration or abnormal noises
are heard.
1. Before operation, check whether the tool attachment
is properly attached, i.e. centred in the quick-release
chuck (2).
2. Screw bits are marked with their dimensions and
shape. If you are unsure, always try out first whether
the bit sits in the screw head without play.
8.5
Gear selection
1. Push the gear selector switch (4) to 1
sponding to a low or high speed selection.
Gear 1 :
Suitable for:
Rotational speed:
Torque:
Gear 2 :
Suitable for:
Rotational speed:
Torque:
8.6
Set direction of rotation
ATTENTION
The direction of rotation switch may only be actuated
when idle.
With the direction of rotation switch, you can select the di-
rection of rotation of the product (clockwise or anti-clock-
wise) and secure the product from being switched on un-
intentionally. The arrow on the direction of rotation switch
indicates the working direction.
1. Wait until the product has come to a standstill.
2. Push the direction of rotation switch (10) to the de-
sired position:
– Clockwise rotation: For drilling and screwing
in screws. Press the direction of rotation switch to
the right.
3. Switch lock: Put the direction of rotation switch in the
centre position.
8.7
ATTENTION
The torque adjusting ring may only be actuated when
idle.
Note:
A clear ratcheting sound is heard when reaching the pre-
set torque limit. This noise is caused by the slip clutch.
Note:
You can preset the maximum torque by turning the torque
adjusting ring (3). There are 25 torque levels + 1 drill level.
1. Select the desired torque by turning the torque adjust-
ing ring (3).
2. Start with a lower torque level and increase it as re-
quired.
Level 1
Level
Screws
Drilling
8.8
or 2 corre-
The speed can be steplessly controlled by the on/off
switch. The further you press the on/off switch, the higher
the speed.
0 – 450 rpm
1. To switch on the product, push the on/off switch (9).
Screwing work
2. To switch off, release the on/off switch (9).
Low
If you put the direction of rotation switch (10) in the
High
centre position, the product is secured from being
switched on.
0 - 1600 rpm
8.8.1
Drilling work
This product is equipped with an LED work lamp to illumi-
High
nate the immediate work area and improve visibility in
poorly lit environments.
Low
Do not look directly into the LED work lamp or the light
source.
1. The LED work lamp (8) lights up automatically as
soon as the product is switched on.
Note:
The LED work lamp remains lit up for approx. 10 seconds
after the product is switched off.
8.8.2
1. During work breaks, the product can be hooked onto
the belt with the integrated belt clip (11).
Note:
Make sure that the product is switched off and secured
against being switched on.
www.scheppach.com
– Anti-clockwise rotation: To undo screws. Press
the direction of rotation switch to the left.
Adjusting the torque
On/Off switch (9) (Fig. 1)
LED work lamp (8)
CAUTION
Applying the belt clip (11)
Lowest torque
Highest torque
Level 1 - 25
Level
GB | 19
