Preparing the devices for use
EM 500 receiver
Headphone output,
Headphone volume control (VOL)
LC display
button (UP)
button (DOWN)
button
SET
POWER
(ON/OFF) button
Cable grip for power supply DC cable
DC socket for connection of mains unit (DC-IN)
AF output, XLR-3M socket (AF OUT BAL/UNBAL)
AF output,
AF output level control (AF LEVEL)
Antenna input II (ANT II), BNC socket
Antenna input I (ANT I), BNC socket
1
/
" (6.3 mm) jack socket (PHONES)
4
1
/
" (6.3 mm) jack socket (AF OUT BAL/UNBAL)
4
55
