Table 26. System setup options—Integrated Devices menu (continued)
Integrated Devices
Rear USB Configuration
Table 27. System setup options—Storage menu
Storage
SATA Operation
SATA Operation
Storage Interface
Port Enablement
SMART Reporting
Drive Information
Enable MediaCard
Table 28. System setup options—Display menu
Display
Primary Display
Video Primary Display
Brightness on battery power
Full Screen Logo
Full Screen Logo
NOTE:
USB keyboard and mouse always work in the BIOS setup irrespective of
this setting.
Enables or disables individual USB ports.
By default, Rear Port 1 (Top Left)* is selected.
By default, Rear Port 2 (Top Right)* is selected.
By default, Rear Port 3 (Bottom Left) is selected.
By default, Rear Port 5 (Bottom Right) is selected.
* Denotes a USB 3.0-capable port
NOTE:
USB keyboard and mouse always work in the BIOS setup irrespective of
this setting.
Configures the operating mode of the integrated storage device controller.
Default: RAID On. The storage device is configured to support RAID. (Intel® Rapid
Restore Technology)
NOTE:
Although the default operating mode of the integrated SATA controller is
set to RAID ON, this computer does not support RAID functionality.
Enables or disables the onboard drives.
Default: SATA-0 is ON
Default: SATA-1 is ON
Default: SATA-3 is ON
Default: M.2 PCIe SDD-0 is ON
Enable or disable SMART Reporting during system startup.
Default: OFF
Displays the information of various onboard drives.
Turn on or off all media cards, or enable or disable the media card in read-only state.
By default, Secure Digital (SD) Card is selected.
Set or change the primary video controller when multi controllers are available in the
system.
By default, Auto is selected.
Sets the screen brightness when the computer is running on battery power.
Default: 50
Displays the full screen logo if the screen resolution matches the image of the logo.
