EN
Soft Focus Filter
The Ovation E-910FC comes with a soft-focus filter. To keep the soft-focus filter in good condition:
•
Ensure that no fingerprints are left on the filter, as this may cause the filter to heat unevenly and eventually warp.
•
When placing the filter in the holder, follow the orientation direction printed on the filter.
•
When inserting shutter blades into the light path, note that the heat is reflected back at the filter. The deeper the
blades are inserted, and the longer the fixture runs, the more heat gets reflected on to the filter, causing it to warp
and potentially adhere to the shutter blades.
•
If there is a protective film on the soft-focus filter, it must be removed before use. The filter is in a
holder in the metal gobo slot.
•
Do not use the soft-focus filter with gobos or large shutter cuts. Doing so will cause excessive heat
reflection onto the filter, causing it to melt and warp. This filter is intended to eliminate LED imaging
(skittles) when directly viewing the lens.
Control Panel Description
Button
Function
<MENU>
Exits from the current menu or function
<ENTER>
Enables the currently displayed menu or sets the currently selected value into the selected function
<UP>
Navigates upwards through the menu list or increases the numeric value when in a function
<DOWN>
Navigates downwards through the menu list or decreases the numeric value when in a function
3
QUICK REFERENCE GUIDE
*To insert the soft-focus filter, gently squeeze and
slide the filter into the slot under the four filter holders.
To remove, gently squeeze and slide the filter out
from under the filter holders.
Soft-focus filter
Filter holder (x4)
Ovation E-910FC QRG Rev. 21
