The headphones are powered by two R03/LR03 (AAA)
batteries (not included).
The operation indicator b on the right housing of the
headphones lights in red when the [OPR] switch a on
the left housing of the headphones is turned "ON". When
the batteries become weak, the indicator dims or fails to
light. Noise and interference also increase. Change the
batteries if any of the above occurs.
This unit uses an infrared beam. The approximate area
in which the infrared beam from the transmitter (beam
emitter c) can reach the headphones (beam sensor d)
is shown in the fi gure. Install the infrared beam transmitter
within the area indicated.
e: Approx. 3 m
f: Approx. 8 m
● As infrared beams can not pass through walls or
● Do not expose the headphones to direct sunlight or to
Battery installation
Press the battery compartment lid on
the left housing of the headphones to
open the battery compartment, then
remove the lid.
Insert the two batteries.
● Correctly align the + and - poles when inserting.
● Push down on the - pole spring when inserting.
Remove the + poles fi rst when removing.
Firmly close the battery compartment
lid.
When to change the batteries
Installation
Note
window panes, the headphones must be used where
the infrared beam transmitter is directly visible without
any obstructions.
the bright light of an inverter fl uorescent light.
