9. Technical data
Product Category:
Nebulizers
Product Description:
Compressor Nebulizer
Model (code):
NE-C801KD (NE-C801S-KDE(V))
Rating (AC adapter):
100-240V ~ 350mA, 50/60Hz
Rating
12V
(Compressor Nebulizer):
Operating Condition:
Intermittent operation 20min. ON / 40min. OFF
Operating Temperature/
+10°C to +40°C / 30% to 85% RH (non-condensing) / 700 to 1060 hPa
Humidity/Air Pressure:
Storage and Transport
-20°C to +60°C / 10% to 95% RH (non-condensing) / 700 to 1060 hPa
Temperature/Humidity/
Air Pressure:
Weight:
Approx. 290g (compressor only)
Dimensions:
Approx. 142 (W) × 72 (H) × 98 (D) mm (compressor only)
Contents:
Compressor, Nebulizer Kit, Kids Accessory (Smile Bear),
Air Tube (PVC, 100cm), 5 pcs Spare Air Filters, Mouthpiece,
Infant Mask (PVC), Child Mask (PVC), AC adapter, Storage Bag,
Instruction Manual, Warranty Card.
Classifications:
Class ll (Protection against electric shock),
Type BF (Applied part); Mouthpiece, Child Mask, Infant Mask
IP21 (Ingress Protection)
Notes:
• Subject to technical modification without prior notice.
• This OMRON product is produced under the strict quality system of OMRON HEALTHCARE Co., Ltd.,
Japan.
• The device may not work if the temperature and voltage conditions are different to those defined in
the specifications.
• Do not use the device where it may be exposed to flammable gas.
• This device fulfils the provisions of the EC directive 93/42/EEC (Medical Device Directive) and the
European Standard EN13544-1:2007+A1:2009, Respiratory therapy equipment - Part1: Nebulizing
systems and their components.
• IP classification is degrees of protection provided by enclosures in accordance with IEC 60529. The
compressor and the AC adapter are protected against solid foreign objects of 12 mm diameter and
greater such as a finger, and against vertically falling water drops which may cause issues during a
normal operation.
IP XX
22
0.8A
Symbols description
Need for the user to consult the instructions for use
Applied part - Type BF
Degree of protection against electric shock (leakage current)
Class ll
Protection against electric shock
Ingress protection degree provided by IEC 60529
