Specifications
Input voltage
230 V 50 Hz
Max. pulling force
500 N
Power
80 Watt
Nominal torque
3.0 Nm
Standby consumption
4 Watt
Max. door weight
60 kg
Motor
Type
worm gear type
Voltage
24 V
Noise level
55 dB
Drive mechanism
Length of travel
2.305 m
Speed
10 cm /sec
Lighting
LED 1W
Safety
Electronically
automatic force adjustment
Electrically
thermal fuse in transformer
Limit switch adjustment
manually
Dimensions
Length (overall)
2.95 m
Required clearance height
min. 35 mm
Suspended weight
10 kg
Radio receiver
Memory
8 remote controls
Operating frequency
433,92 MHz
Battery
12 V, type 27 A (10A12-WH)
All manuals and user guides at all-guides.com
16
1. Drive unit
2. Hardware bag
3. Header bracket
4. Door bracket
5. Door-side rail complete
6. Drive-side rail complete
7. Rail, intermediate section (piece)
8. Rail connector (piece)
9. Trolley
10. Chain with actuator complete
11. Mounting bracket (per unit)
12. Pushbutton with cable
13. External release set
14. LED module
15. Control board
16. Referenceswitch (Microswitch)
17. Transformer
18. Remote control
19. Remote control battery (10A12-WH)
17
1. 54332EML
2. 5002EX
3. 760EML
4. 770EML
5. EQL03/1702EML External emergency release mechanism
9
Spare parts
Accessory
(optional)
Remote control (2-channel)
External 2-channel radio receiver to operate
different drives with the 2-channel remote control
(remotes not included)
Keyswitch with cable
Photocells
(Door reverses automatically without touching an
obstacle)
