4 Apparaatinstallatie
Schakelaarstanden
PR 5110-1
ON: ---
OFF: S1, S2, S3, S4, S5
Coniguratie PR 5110
[
] - [oP 10] - [LInE] - [rS485]
[
] - [oP 12] - [tokEn] - [oFF]
[
] - [oP 13] - [SEndModE] - [WAIt]
[
] - [oP 14] - [WEIght] - [FolloW]
[
] - [oP 15] - [WPkEy] - [SElEct]
4.4.2
RS-232-interface
NL-33
PR 5110-2
ON: ---
OFF: S1, S2, S3, S4, S5
In het externe display zit standaard een RS-232-interface ingebouwd.
RS-485
Com 1
RS-232
1
9
Externe aansluiting
Schakelkastbehuizing
Tafelbehuizing
Technische gegevens
Benaming
Aantal kanalen
Type
Overdrachtssnelheid [bit/s]
PR 5110-3
ON: S1, S2, S3
OFF: S4, S5
Coniguratie PR 5410
- [Serial ports parameter] - [Remote display]
- [Slot 1/2 RS485]
RS-232
Com 2
LOCK supply voltage
1
2
3
4
5
9‑polige D‑Sub bus (male)
5‑polige insteekklem
Gegevens
1
RS-232, full-duplex
2.400...19.200
Extern display PR 5110
PR 5410
ON: S1, S3, S4, S5
OFF: S2
