Inspired by life
n The attendant must reduce the speed of the
wheelchair using the push handles.
n If you are using the wheelchair yourself, slow
down the wheelchair with your hands only on
the hoops. Never use the brake, as you may lose
control of the wheelchair.
Others
n Drive carefully on roads that are slippery due to
rain, ice or snow!
n Do not allow the wheelchair to come into con-
tact with seawater: seawater is aggressive and
will affect the wheelchair.
n Do not allow the wheelchair to come into
contact with sand: sand can penetrate into the
rotating parts of the wheelchair, causing unne-
cessarily rapid wear and tear.
n Do not place the wheelchair in direct sunlight:
the upholstery may become too hot and cause
sunburn or skin sensitization.
n If you are under the influence of substances that
may affect your ability to drive, you should not
drive the wheelchair.
n You must have sufficient eyesight to be able to
drive the wheelchair safely in the respective use
situation.
n Be careful not to let any items of clothing hang
loose. These could get between the wheels.
n Never lift the wheelchair by the armrests, as this
can lead to dangerous situations.
EN16
EN16
Settings & Customizations.
The NEOX has a wide range of settings and adjust-
ment options that can be used to adapt the wheel-
chair to all user requirements. The NEOX instructi-
onal videos that you can find online on our website
or directly via the QR code on the right, explain all
the settings clearly. The NEOX configurator provides
support to achieve the right individual seat settings
for your client. Life & Mobility recommends that you
consult your dealer regarding the correct settings.
You can make the simple adjustments yourself, wit-
hout the use of tools.
Frame height
Use the QR code above or check out our website
for the complete NEOX frame height chart with the
right setup advice for your client.
Based on the lower leg length, way of locomotion,
activity level, user profile and desired front and rear
wheel size, an exact recommendation is given for the
positioning of the front and rear wheel.
Frame height is measured at the front of the wheel-
chair from the top of the frame's seat tube to the
ground.
Frame height front wheelchair with telescope
1. Loosen the 2 Allen screws (A).
2. Slide the front wheel telescope in or out of the
front module until the front of the wheelchair has
the desired frame height.
A A
3. Place the nut plate and Allen screws (A) in the
correct position and tighten
4. Repeat for the other front wheel.
Frame height front wheelchair without telescope:
1. Remove the 2 Allen screws (A) and the front
wheel.
2. Place the front wheel at the correct height on
the front module to achieve the desired frame
height.
EN17
EN17
