4.6 Operation of electronic dishwasher with LCD display
Fig. 14 shows the control panel of the dishwasher and command references
KEY FOR SELECTION OF THE WASH TIMES
KEY FOR SELECTION OF THE WASH TIMES
DISPLAY LINE
1
With dishwasher ready: selected program code
During the wash cycle: countdown of seconds to the end
In case of anomaly: anomaly code
2
Dishwasher status e.g. loading, heating, ready (text may be
scrolling)
In case of anomalies: description of the anomaly
3
Tank temperature
4
Boiler temperature
In case of anomaly: tips to solve the problem.
The sequence of operations to be carried out for the washing operation is shown below: some of
these operations are performed automatically by the dishwasher.
ATTENTION
PAY ATTENTION WHEN THE OPENING AND CLOSING THE DOOR/LID OF THE DISHWASHER.
DO NOT USE THE DISHWASHER WHEN WEARING CLOTHING/ITEMS THAT COULD BECOME CAUGHT IN
THE DISHWASHER COMPONENTS, LIMITING CAPACITY FOR NORMAL MOVEMENT.
CONTROLS
ON/OFF KEY
CYCLE START KEY
EXTRA RINSE KEY
DRAIN PUMP KEY
LCD DISPLAY
DESCRIPTION ON THE DISPLAY
25
REF.
1
2
3
4
5
6
7
Fig. 14a
LCD DISPLAY
EN
25
