EN
ENVIRONMENT
The device is delivered in a package to protect it against any possible
transport damage. The packaging is made from non-processed
material and can be recycled. Throw the materials to appropriate
colour containers for selective waste collection.
Protect the environment and do not throw used batteries
into household wastes. Return them to the point of sale
or a special recycling centre.
Used electrical equipment (including the computer and
power supply) are recyclable. Do not throw them out with
household waste as they may contain substances dangerous to the
health and environment. You can actively contribute to sustainable
use of natural resources and the protection of the natural
environment by handing the used device to a recycling centre for used
electrical devices.
ASSEMBLY
The device must be assembled carefully by an adult. In case of doubt,
ask a more experienced person for help.
•
Prior to the assembly, make sure the set contains all
the listed elements and whether none of the parts was
damaged during transport. If any parts are missing or you have
any other reservations, contact the seller.
•
Have a look at the drawings and explanations and follow the
assembly manual when assembling the device.
•
Be careful during the assembly. There is a risk of injury when
using the tools and parts.
•
Remember to keep your surroundings safe. Do not let tools
and parts lie around in chaos. Remember that plastic foil and
bags pose o suffocation risk to small children.
•
Assembly parts necessary for a specific step in
the assembly manual are shown in pictures and included in
instructions. Use the elements indicated in the assembly
manual.
•
Do not tighten parts completely during the first stages
of the assembly. Tighten connections after all parts are placed
and fitted properly.
•
The manufacturer may have assembled some parts.
ASSEMBLY DIAGRAM (→ See page 2)
ATTENTION! Do not use parts other than those provided by the
manufacturer.
PARTS LIST
NO.
DESCRIPTION
1
Main frame
2
Lower frame
3
Treadmill column
4
Upper frame
5
Motor frame
6
Front roller
7
Rear roller
8
Cylinder
9
Running board t15*520*1130
10
Running belt t1.4*400*2520
11
IGBT 200-J5
12
Nut M6
13
Motor
14
Controller
15
Computer
16
Upper motor cover
17
Lower motor cover
18
Left main frame end cap
19
Right main frame end cap
20
Main frame edge
21
Lower frame handling wheel
22
Railing end cap
23
Foam grips
24
Plastic feet
25
Damper
26
Electrical connector
27
Fuse
15
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
ASSEMBLY MANUAL (→ See page 3)
QUANTITY
CAUTION! Follow the steps below during the assembly and use tools
supplied with the product. Prepare sufficient space for the assembly
1
operation. It is advisable to assemble the product with another person
1
2
because of the weight of some elements.
1
FOLDING AND UNFOLDING (→ See page 5)
1
1
FOLDING THE DEVICE
2
NOTE! Before assembling, check carefully that all screws are
1
tightened.
1
NOTE! Be careful with your hands and fingers when folding so that
1
they do not get crushed.
1
Lift the running belt of the device to the horizontal position until the
8
lock clicks.
1
1
UNFOLDING THE DEVICE
1
PLEASE NOTE! Ensure there are no third party or animals in the
1
immediate treadmill vicinity when its belt is lowered.
1
Hold the running belt and release the folding lock (indicated with the
1
arrow). Lower the belt to the railing level. The belt will now descend
1
automatically.
2
2
ADJUSTMENTS
2
Levelling
2
Level the device by rotating the levelling feet in the rear and front
4
base.
8
1
1
Power cord
Power cord clamp 6W3-4
Inclination adjustment
Inclination adjustment lock
Rubber damper washers
Damper
Sticky battens
Heart rate sensor / Quick speed change +/-
Heart rate sensor / Quick Start/Stop button
Safety key
Signal cable
Hexagonal screw M8*45
Hexagonal screw M8*60
Hexagonal screw M8*12
Hexagonal screw M8*20
Hexagonal screw M8*25
Hexagonal screw M8*40
Hexagonal screw Φ10*15*(M8*10)
Hexagonal screw M8*15
Hexagonal screw M8*30
Hexagonal screw M8*25
Hexagonal bolt M8*45
Hexagonal screw M8*40
Bolt ST4. 2*12
Bolt ST4. 2*45
Bolt ST4. 2*20
Bolt ST4. 2*15
Bolt M5*10
Nut M8
Washer Φ9* Φ16*t1.0
Spring washer D8
Nut Φ 5.2* Φ 10*t1
Sensor 400
Magnetic ring
Single-conductor cable
Two-conductor cable
Upper connecting cable 400 mm
Heart rate sensor cable (1) 400 mm
Heart rate sensor cable (2) 400 mm
Wrench S17 / S13
Wrench S6 / 80*80 mm
Bolt M6*40
1
1
2
2
2
2
4
1
1
1
1
1
2
2
2
2
1
2
2
1
2
9
2
2
2
8
22
4
8
13
6
1
1
1
1
2
1
1
1
1
1
8
