6. Screw the main rail to the Way-out
using the ten 3,5 x 10 mm screws
(Figure
88, pos. 1). Make sure all screw
holes match up.
7. Screw the bracket
the main rail in the front position using the
knob screw
(Figure
you connect the knob screw to the slide
nut
(Figure
89, pos. 2).
8. Hook the bracket firmly around the frame
of the window in the lowest position pos
sible.
9. Pull the bracket as far towards you as pos
sible
(Figure
90, pos 1) so it clamps prop
erly.
10. Tighten the screw cap
11. Close the window as far as possible.
(Figure
89, pos. 3) to
89, pos. 1). Make sure
(Figure
90, pos. 2).
Figure 88.
Figure 89.
Figure 90.
