15. Fill up the open spaces
with the delivered isolation foam
(Figure
102, pos. 2), cut the foam if neces
sary*.
16. Continue in chapter 'assembly air condi
tioning hose'.
* Extra isolation foam (product
code: 875201) can be ordered via
www.eurom.nl
Assembly air condi oning hose
CAUTION
Only suitable for mobile air condi oning systems with a cooling capacity of up to
18,000 BTU / 4,100 wa s.
CAUTION
Only suitable for an air condi oning hose with a diameter of 150 mm.
Two di erent air condi oning hoses can be installed to the Window Way-out:
• With a click system, for a hose with a collar
• With a rota ng system, for a hose without a collar
50
(Figure
102, pos. 1)
.
Figure 102.
(Figure
103, pos. 1).
Figure
104, pos. 1).
