Anleitung_NPFP_15000_SPK7__ 10.06.13 15:45 Seite 13
Submersible pump
n
Universal hose connection
n
Original operating instructions
n
3. Intended use
The equipment you have purchased is designed to
pump water with a maximum temperature of 35 °C.
This equipment must never be used for other liquids,
especially not for engine fuels, cleaning agents and
other chemically-based products!
The equipment can be used wherever you want to
move water, e.g. in the house, in the garden, and for
many other applications. It must not be used to
operate swimming pools!
If you want to use the equipment in bodies of water
with a natural, muddy bottom, place the equipment in
a slightly elevated position, e.g. on bricks.
The equipment is not designed for continuous
operation, e.g. as a circulating pump in a pond. In this
case the equipment's anticipated life will be greatly
shortened because the equipment was not designed
for continuous loading.
The equipment may only be used for its intended
purpose. Any other use is deemed to be a case of
misuse. The user/operator and not the manufacturer
will be liable for any damage or injuries of any kind
which result from such misuse.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
equipment is used in commercial, trade or industrial
businesses or for equivalent purposes.
The water may be contaminated by escaping
lubricating oil/lubricant.
4. Technical data
Mains connection
Power rating
Max. pumping rate
Max. delivery head
Max. submersion depth
Max. water temperature
Hose connection
approx. 42 mm (G 11/4) IG
Max. size of foreign bodies:
Switching point height: ON
Switching point height: OFF
Suction height:
Protection type.
5. Before starting
5.1 Fitting the handle (Fig. 3/4)
Plug the handle (1) onto pump (Fig. 3).
n
Secure the handle (1) with the fastening nut (3)
n
(Fig. 4).
5.2 Installation
The equipment can be installed either:
Stationary with a rigid pipe line
n
or
Stationary with a flexible hose line
n
Before you use the pump, clarify any possible special
conditions which need to be fulfilled for the
installation!
For example, additional safety measures may be
needed if damage to property could result from a
power failure, soiling or a defective gasket.
Examples of such safety measures:
Pumps running in parallel on a separately protected
power circuit, moisture sensors for switching off the
pumps, and similar safety arrangements.
Be sure to consult a professional plumber if you have
any doubt.
Note:
The maximum pumping rate is possible only with the
largest possible line diameter; if smaller hoses or
pipes are connected, the pumping rate will be
reduced. If the universal hose connection (Fig. 1/Item
2) is used, it should be shortened (as shown in Fig. 2)
to the connection actually used in order not to reduce
the pumping rate unnecessarily. Flexible hoses must
be fastened to the universal hose connection with a
hose clip (not included in the scope of supply).
GBR
230 V ~ 50 Hz
750 W
15000 l/h
10 m
5 m
35°C
Ø 5 mm
max. approx. 12 cm
min. approx. 3 cm
min. 2 mm
IPX8
13
