Installing the cooktops
7.4
Retrofitting with pot holders (CVH1350M,
CVH1525M)
The models CVH1350M, CVH1525M can be retrofitted with pot holders.
1. Use the pot holder as a template to mark the 4 drill holes on the countertop.
2. Drill the 4 holes into the countertop at the marked locations.
3. Fasten the pot holders on the countertop (fig. 6, page 6).
7.5
Connecting the device to the gas supply
The assembly and installation of the gas connection must be performed
by a qualified person who has demonstrated skill and knowledge related
to the construction, installation and operation of gas appliances and has
received safety training to identify and avoid the hazards involved.
!
WARNING! Explosion hazard
• Only use propane or butane gas containers with a certified pressure
reduction valve and suitable head.
• Compare the pressure information on the data plate with the pres-
sure information on the propane or butane gas containers.
• Avoid any stress on the gas pipe system during and after installation.
I
NOTE
• The gas installation must be made in accordance with
EN ISO 10239.
• Observe additional possible national safety requirements and
requirements of the relevant marine association or boat builders.
Observe the following instructions for the connection:
• Observe the national requirements.
• Only use a steel pipe Ø 8 x 1 mm (welded, seamless steel or stainless steel) for the
connection.
• Fasten the gas line to the side or rear wall of the surrounding furniture parts so that
no loads are placed on the actuators.
• The entire gas line must be free of stress.
1. Connect the pipes as shown (fig. 7, page 7).
22
CVH1350M(G)(P), CVH1525M(G)(P)
EN
