Connections
AUX INPUT
*
Sold Seperately
AUX/CAMERA/CAN cable
IGNITION
(Red)
GND
(Black)
POWER ANT
(Blue)
BATTERY
(Yellow)
* Notice that the configuration of commercially available 4-pole mini AV plugs is notstandardized. For details,
refer to Owner's Manual published on our website.
All manuals and user guides at all-guides.com
Sold Seperately
REMOTE OUT
(Brown)
CAMERA IN
10A
USB Extension cable (Included)
REMOTE TURN-ON
(Blue/White)
REVERSE
(Orange/White)
PARKING BRAKE
(Yellow/Blue)
(Green)
(Green/Black)
(White)
(White/Black)
(Grey/Black)
(Grey)
(Violet/Black)
(Violet)
Owner's manual
To Video Output Terminal
To Audio Output Terminal (R, L)
To remote input lead
To camera
To CAN Interface box
Antenna
ISO Antenna Plug
Microphone (Included)
Front Left
Amplifier
Front Right
Rear Left
Amplifier
Rear Right
Amplifier
Subwoofers
iPhone 5 or later
To amplifier or equalizer
To plus side of the back lamp
signal lead of the car
To the parking brake signal lead
To power antenna
Ignition key
Rear Left
Front Left
Front Right
Rear Right
Connections
Battery
Speakers
9
-EN
