10- Instellingen Volt/Hz patroon
Functie
LCD Display
Code Nr.
10-0
(V/F Selection)
10-1
(Torque Boost)
10-2
(Motor noLoad Amp)
10-3
(Motor rated Slip)
10-4
(Max frequency)
10-5
(Max Voltage)
10-6
(Mid frequency)
10-7
(Mid Voltage)
10-8
(Min frequency)
10-9
(Min Voltage)
11- Instellingen PID
Functie
LCD Display
Code Nr.
11-0
(PID Mode Sel)
11-1
(Feedback Gain)
11-2
(PID Gain)
11-3
(PID I Time)
11-4
(PID D Time)
11-5
(PID Offset)
11-6
(PID Offset Adj)
11-7
(Output Filter T)
Omschrijving
Volts/Hz patroon
Aanpassing Volts/Hz curve
(Koppel Boost) (%)
Nullaststroom motor
(Amps AC)
Motor slip Compensatie (%)
Maximum frequentie (Hz)
Maximum frequency spannings
ratio (%)
Midden frequentie (Hz)
Midden frequentie spannings
ratio (%)
Minimum frequentie (Hz)
Minimum frequentie spannings
ratio (%)
Omschrijving
Instellingsselectie
Feedback Gain (%)
Proportional Gain (%)
Integration tijd (Sec.)
Differentiation tijd (Sec.)
PID offset
PID offset aanpassing (%)
Output lag filter tijd (Sec.)
Instellingen
0 - 18
0 – 30.0
-----
0.0 – 100.0
0.20 - 650.00
0.0 - 100.0
0.10 - 650.00
0.0 - 100.0
0.10 - 650.00
0.0 - 100.0
Instellingen
0000: Uitgeschakeld
0001: Bias D Controle
0002: Terugkoppelings D Controle
0003: Bias D Reversed
Characteristics Control
0004: Feedback D Reversed
Characteristics Control
0005: Frequency Command + Bias D
Control
0006: Frequency Command +
Feedback D Control
0007: Frequency Command + Bias D
Reversed Characteristics
Control
0008: Frequency Command +
Feedback D Reversed
Characteristics Control
0.00 - 10.00
0.0 - 10.0
0.0 - 100.0
0.00 - 10.00
0000: Positief
0001: Negatief
0 – 109
0.0 - 2.5
Fabrieks
Opmer-
Instelling
king
0/9
*4*6
0.0
*1*6
*5*6
0.0
*1*6
50.00/
*4*6
60.00
100.0
*6
2.50/3.00
*4*6
7.5
*6
0.50
*6
7.5
*6
Fabrieks
Opmer-
Instelling
king
0000
1.00
*1
1.0
*1
10.0
*1
0.00
*1
0000
*1
0
*1
0.0
*1
10
