Note: Voice input
• Press and hold the "Voice Assistant (18) " button for
voice input and speak into the microphone on the remote
control. The LED lights up during voice input. As soon as
you release the button, voice input is cancelled and the
LED goes out.
Note: Terminate Bluetooth connection
• If necessary, disconnect the Bluetooth connection as
follows
• Press and hold the "OK (16)" +
"Back (3) " buttons for 3 seconds.
5.3 Special functions
1. "Mute (5)
" button: If the button is pressed for 1
second or longer, the available short cuts are displayed
2. "Guide (12)
" button: If the button is pressed for 1
second or longer, the channel list is displayed
3. "Multi View (17)
" button: Ambient mode is displayed
if the button is pressed for 1 second or longer.
5.4 Setting up infrared mode
If your Smart TV does not support control via Bluetooth remote
control, you can also use this remote control in infrared mode.
To do this, use one of the following codes to set your remote
control to your Smart TV
Code-1: Press and hold the "OK (16)" + "D+(6)" button for 3
seconds until the LED flashes twice. (Factory reset)
Code-2: Press and hold the "OK (16)" + "N (7)" buttons for 3
seconds until the LED flashes twice.
Code-3: Press and hold the "OK (16)" + "a (8)" buttons for 3
seconds until the LED flashes twice.
Code-4: Press and hold the "OK (16)" + "Mute (5)" buttons for
3 seconds until the LED flashes twice.
Note: Voice assistant
• The voice assistant only works in Bluetooth mode
6
6. Infrared learning function
This remote control is equipped with a learning function. This
allows you to transfer functions from your original remote
control to this replacement remote control.
Note: Before you start the learning function
• Please ensure that the replacement remote control or
the batteries used in your original remote control are
sufficiently charged. Change them if necessary.
• Place your original remote control and the remote control
next to each other so that the infrared diodes of the
remote controls are directly opposite each other.
• If necessary, correct the height of both remote controls to
achieve optimal alignment.
• The distance between the two remote controls should be
approx. 3 - 5 cm.
6.1 Activating the learning mode
Press and hold the "OK (16)" + "Voice Assistant (18) "
buttons for 3 seconds until the LED lights up. The replacement
remote control is now in learning mode.
6.2 Teach-in buttons
1. Briefly press the button on the replacement remote control
to which you want to transfer a new function.
2. Then press and hold the button on the original remote
control whose function you want to transfer for 1-2
seconds. If the LED on the replacement remote control
flashes twice, the new function has been successfully
programmed. If the LED flashes 6 times, the learning
process was not successful. If necessary, correct the
position of the two remote controls in relation to each
other and repeat steps 1 and 2.
3. To teach more buttons, repeat steps 1 and 2.
4. To exit learning mode, press the "Voice Assistant (18)
" button
ORIGINAL
3- 5 cm
