Establishing the connection
1
6
1 2
18
B LE G er ä te
BLE devices
C E 2 0 0 2D
0 2/ 05
∧
∨
+
E S C
Fig. 23: Selecting the channel extension
7.
On the DIN-rail timer, use the keys on the left (⋀/⋁) to select from the list the channel extension to be
connected, and confirm with
The connected channel extension is indicated by #.
8.
Select a new channel extension with the keys on the left (⋀/⋁) and confirm with
1
6
12
18
CH 3
Verb un den :
Connected:
T S 25 0 01
3
4
Me n u
Fig. 24: Channel extension is connected to the DIN-rail timer
9.
The channel extension displays the name of the connected device if there is an active connection
(Fig. 24/
).
1
The display switches between the name of the connected device and the current date and time.
ð
After a connection is established, the channel name switches from "A" and "B" to "3" and
"4", "5" and "6" or "7" and "8".
10. If the DIN-rail timer or the channel extension is protected by PIN, enter the PIN on the DIN-rail timer.
