It is recommended to cover the surface of the pool during the operation of the product to help increase the level of chlorine
in the pool.
ATTACHING A BASE TO THE CHLORINATOR
Follow the below instructions. There must
be two holes with a diameter of 8 mm and
a spacing of 155 mm on the base. The
product can be fixed on a cement base or
a wooden platform. The total weight of the
base should not be less than 18 kg to
protect the chlorinator from accidentally
falling over.
MAINTENANCE
ELECTROLYTIC CELL
To clean the electrolytic cell, follow the instruction in the section
reflect actual product. Not to scale. In order to maintain the best results, we recommend opening and checking the electrodes
every month. However, if the water quality of the swimming pool is hard water (high content of calcium and magnesium
ions), the electrodes may need to be cleaned manually on a regular basis. To clean the electrolytic cell, it is suggested to
use a solution of 50% water/50% vinegar, or check with your pool dealer the suitable chemical product. Be sure to avoid
chemical product that can damage the Titanium plate.
WATER CHEMICAL BALANCE
Available chlorine
Combined chlorine
pH value
Total alkalinity
The hardness of calcium
Stabilizer (cyanuric acid)
• If the concentration of chlorine exceed the recommended level, it can be dangerous to use the pool. Test the chemical
balance before using the pool. If using the test strip, check the expiration date, as the test result may be inaccurate if
passed the expiration date.
• It is recommended to check the level of the chemical in the water every day and before use.
STORAGE
• Remove all accessories; be sure to clean and dry all before the storage. If all the parts are not completely dry, mold
may result.
• We strongly recommend disassembling the product during the off-season (winter months) and storing it in a dry place
with a moderate temperature between 10ºC/50ºF and 38ºC/100ºF.
WARRANTY TERMS
For information concerning warranty terms, visit our website at: www.bestwaycorp.com.
Minimum
0
0
7.2
40 ppm
50 ppm
10 ppm
5
. Drawings are for illustration purposes only. May not
Best Value
0.5 - 3.0 ppm
0
7.4 - 7.6
80 - 100 ppm
100- 250 ppm
20 - 40 ppm
2-M6 nut
2-M6 bolt
≥18KG
Maximum
3.0 ppm
0.2 ppm
7.8
120 ppm
350 ppm
50 ppm
