Heuptasje met aansluitkabel
English
9 Connecting and Disconnecting AP
Battery Bag with Connecting Cable
9.1
Connecting AP belt bag with connecting cable
to a STIHL cordless product with a socket
► Hold connecting cable plug (1) so that the arrow on its side
lines up with the arrow point on the socket (2).
► Insert the connecting cable plug (1) in the socket (2).
9.2
Connecting AP belt bag with connecting cable
to a STIHL cordless product with a battery
compartment for STIHL AP batteries
3
2
1
► Hold connecting cable plug (1) so that the arrow on its side
lines up with the arrow point on the socket (2) of the AP
adapter (3).
30
All manuals and user guides at all-guides.com
2
1
3
9 Connecting and Disconnecting AP Battery Bag with Connecting Cable
► Insert the connecting cable plug (1) in the socket (2) on
the AP adapter (3).
► Push AP adapter (3) into the battery compartment (4).
9.3
Disconnecting AP Belt Bag with Connecting
Cable
► Switch off the cordless product.
► Grip the connecting cable plug with your hand.
► Pull connecting cable plug out of the socket or the AP
adapter.
► Remove the battery.
10 Testing the Battery
10.1 Testing the Battery
► Press button on battery.
The LEDs glow or flash.
► If the LEDs do not glow or flash: Do not use the battery
and contact your STIHL servicing dealer.
There is a malfunction in the battery.
11 After Finishing Work
11.1 After Finishing Work
► Switch off the cordless product.
► Pull connecting cable plug out of the socket or the AP
adapter.
► Remove the battery.
► If the battery is wet: Allow the battery to dry.
► Clean the AP belt bag with connecting cable.
► Clean the battery.
0458-728-9621-A
