Steps
1. Align and place the top cover (side bezel) with the grooves on the chassis.
2. Slide the top cover (side bezel) towards to the front of the system unit to install it.
Next steps
NOTE:
Turn the optional SMA antenna to a convenient angle after safely sliding back the top cover (side bezel) on the chassis.
1. Follow the procedure in
Top Cover (side bezel)
Removing the side cover
Prerequisites
1. Follow the procedure in
NOTE:
Ensure that you remove the security cable from the security-cable slot (if applicable).
About this task
The following images indicate the location of the side cover and provide a visual representation of the removal procedure.
24
Demonteren en hermonteren
after working inside your
computer.
before working inside your
computer.
