Steps
1. Replace the graphics card into the slot on the riser card until it clicks into place.
2. Close the expansion card latch and press it until it clicks into place.
Next steps
1. Install the
riser
card.
2. Install the
fan
assembly.
NOTE:
This step is valid for system configuration that is shipped with 80 W CPU.
3. Install the
front
bezel.
4. Install the
top cover (side
5. Install the
side
cover.
6. Follow the procedure in
bezel).
after working inside your
computer.
Demonteren en hermonteren
55
