1.3. Belangrijke onderdelen
Binnenunit:
Cube HP Solo M 06 / M 08 / M 12 / M 15
Water inlet
= Inlaat van de
Drain
Drain
buitenunit
Water outlet 1
= Vertrek naar cv
installatie
Heating(Water outlet 1)
Heating(Water outlet 1)
Water outlet 2
Water inlet
Water inlet
= Vertrek naar cv
boiler (indien niet
nodig afstoppen)
Domestic hot water
Domestic hot water
(Water outlet 2)
(Water outlet 2)
Plate heat exchanger
Plate heat exchanger
Electric heater
Electric heater
Electric 3-way valve
Electric 3-way valve
Water pump
Water pump
CUBE HP SOLO M
|
11
