Please note
The mains socket must be protected by at least a 16
amp fuse.
If a fuse should blow when you switch on the appliance,
this may be because other electrical appliances which
have a high current draw are connected to the same
power circuit.
To prevent the fuse from blowing, select the lowest
power setting before switching the appliance on, and
increase the power only once it
is running.
Fold out picture pages.
Before using for the first time
1*
Figure
Push the handle onto the flexible tube and until it engages.
2*
Figure
Push the crevice nozzle and upholstery nozzle back into the
accessories holder as indicated.
Setting up
3
Figure
a) Push the flexible hose adapter into the air intake opening on
the vacuum cleaner lid until it engages.
b) To remove the flexible hose, press the two lugs together and
pull the tube out.
4*
Figure
a) Push the handle into the suction pipe/telescopic tube.
To remove it, turn the handle slightly and pull it off the tube.
b) Push the handle straight into the telescopic tube until it
engages.
To release the connection, squeeze the collar sleeve and
pull the handle out.
5*
Figure
a) Connect the floor tool and the telescopic tube together.
b) Push the telescopic tube straight into the
connecting piece of the floor tool until it engages.
To release the connection, squeeze the locking collar and
pull the telescopic tube out.
6*
Figure
a) Connect the suction pipes together, or
b) Unlock the telescopic tube to adjust its length by moving
the sliding switch in the direction of the arrow.
7
Figure
Holding the power cord by the plug, pull out the required
length and plug it into the mains socket.
8
All manuals and user guides at all-guides.com
Figure
Figure
Vacuuming
Figure
Figure
Adjust the "autofloor" floor tool:
If you are vacuuming varying types of floor coverings (hard
floors <-> carpets), we recommend that you use the
automatic setting so that the nozzle adjusts automatically
to the floor and you do not need to switch over the nozzle
setting.
Figure
Figure
a) Crevice nozzle for vacuuming crevices and corners, etc.
b) Upholstery nozzle for vacuuming upholstered furniture,
c) Hard furnishings brush
d) Hard-floor brush
Figure
Turbo brush
If your vacuum cleaner is equipped with a turbo brush, please
consult the accompanying instruction manual for notes on use
and maintenance.
* Depending on equipment
8
Press the on/off button in the direction of the arrow to
switch your vacuum cleaner on/off.
9
Adjust the suction by turning the on/off button in the
direction of the arrow.
10
Adjusting the floor tool:
Rugs and carpets
Hard surfaces
11*
Hard floor setting
Fixed position for vacuuming hard
floors/ parquet
Automatic setting
The nozzle adjusts automatically to the floor covering and
switches from hard floors / parquet
to carpeted floors
Carpet setting
Fixed position for vacuuming rugs and
carpets
12
Remove the upholstery nozzle and crevice nozzle from the
accessories holder as illustrated.
13*
Vacuuming with accessories
Attach the nozzles to the suction pipe or handle as required:
curtains, etc.
For cleaning window frames, cabinets, mouldings, etc.
For vacuuming hard floor coverings (tiles, parquet flooring,
etc.)
14
After use, push the crevice nozzle and upholstery nozzle
back into the accessories holder as indicated.
=>
=>
=>
=> auto
=>
