AIR PANEL P-AP56NAMR
9 AIR PANEL P-AP56NAMR
9.1 NAME OF PARTS
9.2 AIR PANEL P-AP56NAMR
Air panel
P-AP56NAMR
Receiver kit
Indicator lamp
The indicator lamps are turned ON
and flash for the conditions of "Run",
"Timer", "Def" (defrost), "Filter" and
receiving.
Receiver
15
PMML0570 rev.0 - 01/2021
Air inlet grille
Timer
Filter
Def
Run
Emergency
Heat
Cool
Louver
Air outlet
Dip Switch
(Inside of receiver kit)
for function selection setting (this
switch is for installer.)
Switch for emergency
operation
(Refer to the item
operation"
about detail.)
Receiver kit
"9.5 Emergency
