OBJ_BUCH-3270-001.book Page 17 Tuesday, March 27, 2018 10:21 AM
Additional safety warnings
Wear safety goggles.
Use suitable detectors to determine if utility lines are
hidden in the work area or call the local utility company
for assistance. Contact with electric lines can lead to fire
and electric shock. Damaging a gas line can lead to explo-
sion. Penetrating a water line causes property damage or
may cause an electric shock.
Release the On/Off switch and set it to the off position
when the power supply is interrupted, e. g., in case of a
power failure or when the mains plug is pulled. This pre-
vents uncontrolled restarting.
Do not touch grinding and cutting discs before they
have cooled down. The discs can become very hot while
working.
Secure the workpiece. A workpiece clamped with clamp-
ing devices or in a vice is held more secure than by hand.
Products sold in GB only: Your product is fitted with a
BS 1363/A approved electric plug with internal fuse
(ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should
be cut off and an appropriate plug fitted in its place by an
authorised customer service agent. The replacement plug
should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.
Product Description and
Specifications
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
Technical Data
Angle Grinder
Article number
Rated power input
Output power
Rated speed
Grinding disc diameter, max.
Thread of grinder spindle
Thread length (max.) of grinder spindle
Weight according to EPTA-Procedure 01:2014
– with vibration-damping auxiliary handle
– with standard-auxiliary handle
Protection class
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
Bosch Power Tools
Intended Use
The machine is intended for cutting, roughing and brushing of
metal and stone materials without the use of water.
For cutting with bonded abrasives, a special cutting guard
(accessory) must be used.
When cutting in stone, provide for sufficient dust extraction.
With approved sanding tools, the machine can be used for
sanding with sanding discs.
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1 Spindle lock button
2 On/Off switch
3 Lock-off button for On/Off switch
4 Combination wrench for grinding spindle M 10/M14
5 Auxiliary handle (insulated gripping surface)
6 Grinder spindle
7 Protection guard for grinding
8 Mounting flange
9 Grinding wheel*
10 Clamping nut
11 Carbide grinding head*
12 Protection guard for cutting*
13 Cutting disc*
14 Hand guard*
15 Rubber sanding plate*
16 Sanding sheet*
17 Round nut*
18 Cup brush*
19 Handle (insulated gripping surface)
20 Locking screw for protection guard
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
GWS 9-100 P
GWS 9-115 P
3 601 C96 5..
3 601 C96 5..
W
900
W
450
-1
min
11000
mm
100
M 10
mm
22
kg
2.0
kg
1.9
/II
English | 17
GWS 9-125 P
3 601 C96 5..
900
900
450
450
11000
11000
115
125
M 14
M 14
22
22
2.0
2.0
1.9
1.9
/II
/II
1 609 92A 3YF | (27.3.18)
