LEROY-SOMER
Three-phase power supply 208V - 10 % to 240V + 10 %
P
VMA
Fuses
(kW)
rating
(gG)
0.25
31 tl 025
4
0.37
31 tl 037
6
0.55
31 tl 055
6
0.75
31 tl 075
8
0.9
32 tl 090
10
1.1
32 tl 110
10
1.5
32 tl 150
16
1.8
32 tl 180
16
2.2
32 tl 220
16
3
33 tl 300
16
4
33 tl 400
20
5.5
34 tl 550
25
7.5
34 tl 750
32
9
11
Note:
• the mains current value is a typical value which depends on the source impedance. the higher the impedance, the lower the
current.
• the fuses (Ul approved) are intended for installations capable of delivering 5000 a maximum at 480 V.
1.7 - Operating ranges according to the switching frequency
VMA 31
lses 80 lG 0.75 kW - 4-pole
lses 90 s
1.1 kW - 4-pole
VMA 32
lses 90 l
1.5 kW - 4-pole
lses 100 l
2.2 kW - 4-pole
lses 100 lR
3 kW - 4-pole
lses 112 mU 4 kW - 4-pole
VMA 33
lses 132 sU 5.5 kW - 4-pole
lses 132 m
7.5 kW - 4-pole
1.8 - UL conformity
1.8.1 - Specified mains supply
the drive can be incorporated in an installation which can deliver 5000 a rms maximum at a voltage of 264 Vac rms maximum for
230 V (tl) drives or 528 Vac rms maximum for 400 V (t) drives.
1.8.2 - Cables
only class 1 copper cables 60/75 °c (140/167 °F) should be used.
1.8.3 - Fuses
Ul conformity is adhered to if the fuses used are Ul-listed, fast-blow fuses (class cc up to 30 a) with a rating as indicated in the
above table, and if the short-circuit symmetrical current does not exceed 5 ka.
InstallatIon anD maIntenance
VARMECA 30
Variable speed motor or geared motor
Cables
I (A)
(mm
)
2
2
1.5
m16 + m20
3
1.5
m16 + m20
4
1.5
m16 + m20
5
1.5
m16 + m20
5.5
1.5
m16 + m20
6
2.5
m16 + m20
7
2.5
m16 + m20
7.5
2.5
m16 + m20
8
2.5
m16 + m20
12
2.5
m16 + m25
15
4
m16 + m25
20
4
m16 + m25
24
4
m16 + m25
6 kHz
400 - 3000 RPm
400 - 3000 RPm
6 kHz
500 - 3000 RPm
700 - 3000 RPm
700 - 3000 RPm
1500 - 3000 RPm
Switching frequency
6 kHz
700 - 3000 RPm
900 - 3000 RPm
Three-phase power supply 380V - 10 % to 480V + 10 %
VMA
Fuses
PE
rating
(gG)
31 t 025
4
31 t 037
4
31 t 055
6
31 t 075
6
31 t 090
8
31 t 110
10
32 t 150
10
32 t 180
10
32 t 220
10
32 t 300
16
32 t 400
16
33 t 550
16
33 t 750
20
34 t 900
25
34 t 111
32
Switching frequency
8 kHz
600 - 3000 RPm
600 - 3000 RPm
Switching frequency
8 kHz
750 - 3000 RPm
1200 - 3000 RPm
1200 - 3000 RPm
-
9 kHz
1200 - 3000 RPm
1200 - 3000 RPm
3776 en -
2013.06 / k
Cables
I (A)
PE
(mm
)
2
1
1.5
m16 + m20
1.5
1.5
m16 + m20
2
1.5
m16 + m20
3
1.5
m16 + m20
3.5
1.5
m16 + m20
4
1.5
m16 + m20
5
1.5
m16 + m20
5.5
2.5
m16 + m20
6
2.5
m16 + m20
7
2.5
m16 + m20
8
2.5
m16 + m20
12
2.5
m16 + m25
16
4
m16 + m25
19
4
m16 + m25
22
4
m16 + m25
10 kHz
700 - 3000 RPm
700 - 3000 RPm
10 kHz
1000 - 3000 RPm
-
-
-
13
