DX-D 300 U-Arm
Gebruikershandleiding
Illustratie 2-5
Spreiding van de strooistraling (S4) met de ontvanger onder de tafel.
200
180
160
140
120
100
80
60
40
20
0
0
S4
d = 60 cm
1
S4
d = 100 cm
2
28
2000
4000
6000
STROOISTRALING (μGy/h)
SIGNIFICANTE BEZETTINGSZONE
AAN DE RECHTER ZIJDE VAN DE ONTVANGER (PATIËNT
OP EEN BESTRALINGSTAFEL VOORZIEN VAN WIELEN)
RÖNTGENBUIS
BESTRALINGSTAFEL
SIGNIFICANTE BEZETTINGSZONE
AAN DE LINKERZIJDE VAN DE ONTVANGER
(PATIËNT OP EEN BESTRALINGSTAFEL VOORZIEN VAN WIELEN)
8000
10000
12000
S5
Brandpunt
S3
S4
14000
0174A NL 20230322
