TYPE
WET MASS
X
Y
Kg
mm
mm
QAS 150 JD S3A
3055.64
852.18
594.11
QAS 200 JD S3A
3115.74
843.39
605.64
WET MASS = Wet engine and radiator (oil, coolant) and full tank.
NET MASS = Dry engine (without coolant and oil) and emty tank.
BASIC UNIT
Z
NET MASS
X
Y
mm
Kg
mm
mm
1182.6
2425.97
978.67
601.38
1205
2486.07
965.07
615.29
Isometric View
Z
mm
1230.7
1214.1
