E605
Guide for the installer
5.4.7. F
(F
. 6)
ototest
ig
Terminal " "23". Connect, to this terminal, the negative pole of the power supply for the photocell transmitters. This contact is used by the
FOTOTEST function to check the correct operation of the photocells before every closing movement of the automated system. This function
can be activated or disabled by adjusting parameter "S", see paragraph 9.
This input must only be used for the negative pole of the photocell transmitters. Do not connect other devices.
5.4.8. p
oWer supply to Accessories
Terminals " "22 & 24". Output 24 V
The maximum load that can be applied to this output is 500 mA.
Observe the polarity of the power supply - terminal 24 is the positive pole.
5.5. CN5 TERMINAL BOARD
5.5.1. b
Atteries
Terminals " "25 & 26". Connect, to these terminals, the wires coming from any buffer batteries (not supplied). Buffer batteries enable to
compensate for any power supply cut. During normal operation, the control unit keeps the batteries charged thanks to the built-in battery-
charger circuit. The batteries operate whenever the power supply is interrupted.
Use parameter " ", see paragraph 9, to select the behaviour of the automated system when mains power supply is cut.
The number of cycles that can be performed when the automated system is supplied by buffer batteries directly depends on the
battery charge, on the time elapsed from the interruption of the mains power supply, on the type and number of accessories
connected, on the rod type and on the accessories fitted to it.
Refer to the instructions of the automated system for the type of batteries that can be used.
When connecting the batteries, observe the terminal polarity - terminal 26 is the positive pole.
5.6. JP2 CONNECTOR
3-pin rapid connector. This connector is used to connect the receiving module with 433 or 868 Mhz. Fit the receiving module observing
the direction indicated by its compartment (Fig. 8)
Fitting and, if necessary, removing the receiving module must be done only after cutting power to the board.
5.7. JP3 CONNECTOR
The JP3 rapid connector is used to connect the encoder for the motor control.
During closing phase
If an obstacle is detected during the closing phase of the automated system, the encoder operates thus reversing movement up to the
complete opening of the automated system, without disabling any automatic closure.
If it operates three consecutive times, after having reached the opening position, the automated system changes to STOP, and disables
any automatic re-closure. To resume normal operation, send an OPEN or a CLOSE command.
During opening phase
If an obstacle is detected during the opening phase of the automated system, the encode operates thus stopping the movement of the
automated system and performing a brief reversal (approx. 10°), then the control unit changes to STOP, disabling any automatic re-closure.
To resume the normal memory-stored operation, send an OPEN or a CLOSE command.
The connection of the encoder is absolutely necessary for a correct operation of the control unit.
The control board has an integrated 2-channel decoding system (DS, SLH, LC/RC) named OMNIDEC. This system makes it possible to
memory-store both OPEN command and the OPEN/CLOSE command of the automated system - this is made possible by an additional
receiver module and radio controls on the same frequency.
The 3 types of radio codes (DS, LSH, LC/RC) cannot coexist. Only one radio code can be used at a time. To change
over from one code to another, you must delete the existing one (see paragraph 6.3), and repeat the memory-storage
procedure.
Fitting and, if necessary, removing the receiver module must be done only after cutting power to the board.
The receiver module can only be inserted in one position. Orient the module correctly without forcing.
Before proceeding with memorising the radio controls, we recommend you follow the deletion procedure, as described in
par. 6.4.
6.1. Memory storage of DS radio controls
A maximum of two codes can be stored. One on the OPEN channel and one on the OPEN/CLOSE channel.
On the DS radio control, select the required ON-OFF combination for the 12 dip-switches.
1.
On the control unit, press the push-button of the channel you wish to memory store, OP for the OPEN channel or O/C for the
2.
OPEN/CLOSE channel.
The relevant LED on the control unit begins to flash - release the push-button.
3.
On the radio control, press the push-button with which you wish to associate the selected channel.
4.
(F
. 5)
ig
max. 500 mA. Use this output for the power supply to external accessories with 24 V .
6. MEMORY STORING THE RADIO CODE
