Pagina 6
E605
Guide for the installer
6 protective fuses are located on the control unit: 4 of which are self-resettable. The following table summarises the value of each fuse
and the part of the protected circuit:
Fuse
F1=T3.15A 250V 5x20
F5=T10A 250V 5x20
RV1=750mA Self-resetting
F4=700mA Self-resetting
The trash container symbol shown on the product label, on the product or in the instructions indicates that the product,
at the end of its life, must be disposed of separately from other waste products.
The user must therefore bring the equipment that has reached the end of its life to an authorised electrical and
electronic waste disposal centre, or return it to the dealer when new equivalent equipment is purchased, on a one-
to-one basis.
Proper separate collection for the recycling, treatment or compatible environmental disposal of the equipment no longer
in use contributes to avoiding negative effects on the environment and health and favours reuse and/or recycling of
the materials with which the equipment is made.
Unlawful disposal of the product by the user is subject to fines provided for by the regulations in force.
11. PROTECTIVE FUSES
Protection
Primary power supply
Motor power supply
Power supply to
battery-charger circuit
Rod light output
12. DISPOSAL
Fuse
RV2=350mA Self-resetting
F2=700mA Self-resetting
F3=700mA Self-resetting
Protection
Power supply to accessories
Flashing lamp output
Indicator light output
