E605
Guide for the installer
There are 9 control LEDs on the control unit displaying the input status continuously. The meaning of the LEDs is shown on the table
below.
LED
FCA - Opening travel limit FCA
FCC - Closing travel limit FCC
FSW - Photocells input
STOP - STOP command input
OP/CL - Open/Close command input
OPEN - Open command input
CLOSE - Close command input
DL6 - Open/Close command radio input
DL7 - Open command radio input
The bold print indicates the condition of the LEDs with the automated system closed at rest.
The STOP LED must always be ON; it turns off when the command is activated.
If safety devices are not connected, make a connection between terminals 17 & 22. FSW LED must always be ON; it turns off when
the safety devices are engaged.
The control unit has a back-lit large display enabling you to view and program the operating parameters of the automated system.
Furthermore, it always shows the status of the automated system during normal operation. The following table shows all indications on
the display during normal operation:
Displayed value
- -
O P
t c
C L
A S
p r
The operating parameters and their programming are shown on the display of the control unit with two characters: a letter, lower case or
upper case, and a number. The letter indicates the operation of the operating parameter you are modifying, whereas the number indicates
the set value. For example, if you read "b2" on the display, this means you are modifying parameter "b", motor power and obstacle detection
sensitivity, and that it is currently set on "2".
To access the programming phase of the operating parameters, at first start-up, observe the following procedure:
Power up the system and check that all LEDs in the control unit are in the situation indicated in paragraph 7.
1.
Make sure that the display shows value "- -", automated system at rest.
2.
3.
Press and hold down push-button P1 until the name of the first parameter appears on the display with the relevant value.
Press push-button P2 to modify the set value.
4.
To move on the next parameter, press push-button P1.
5.
6.
When 60 seconds have elapsed without any push-button being pressed, the control unit automatically exits the adjustment mode and
any modifications are memory stored. You can manually exit the adjustment phase by scrolling all the parameters with push-button
P1. When the display shows value "- -" you have returned to normal operation.
7. CONTROL LEDs
Travel limit not engaged
Travel limit not engaged
Safety devices not engaged
Command not active
Command active
Command active
Command active
Radio input active
Radio input active
8. OPERATION OF THE DISPLAY
Status of the automated system / description
Automated system closed at rest
Automated system opening or open
Automated system open in pause (only with the selected automatic re-closure)
Automated system closing
Service request: it is shown only if the function was enabled, see paragraph 9 and if the number
of set cycles has been reached.
Control unit in work cycle learning phase
9. OPERATING PARAMETERS
ON
Travel limit engaged
Travel limit engaged
Safety devices engaged
Command active
Command not active
Command not active
Command not active
Radio input not active
Radio input not active
OFF
