In section 10 (Charger indicator) you will fi nd a
table with an explanation of the LED indicator on
the charger.
If the battery pack fails to charge, check for the
following:
•
voltage at the power socket
•
whether there is good contact at the charging
contacts of the charging unit.
If the battery pack still fails to charge, send
•
the charger and charging adapter
•
and the battery pack
to our customer service center.
To ensure that items are properly packaged
and delivered when you send them to us,
please contact our customer service or the
point of sale at which the equipment was
purchased.
When shipping or disposing of batteries and
cordless tools, always ensure that they are
packed individually in plastic bags to prevent
short circuits and fi res.
To ensure that the battery pack provides long ser-
vice, you should take care to recharge it promptly.
You must recharge the battery pack when you
notice that the performance of the device drops.
Never allow the battery pack to become fully di-
scharged. This will cause it to develop a defect.
6.2 Direction of rotation switch (Fig. 4/Item 5)
You can use the direction of rotation switch (5) to
set the tool's direction of rotation.
You can choose between counter-clockwise and
clockwise (L+R). To avoid causing damage to the
gearing, the direction of rotation is allowed to be
changed only when the tool is at a standstill.
6.3 On/Off switch (Fig. 5/Item 4)
Switching on:
Press the On/Off switch (4).
Switching off :
Release the On/Off switch (4).
The lock for the On/Off switch (3) can be used to
secure the tool against being switched on acci-
dentally.
Anl_TE_RW_18_60_Li_SPK13.indb 15
Anl_TE_RW_18_60_Li_SPK13.indb 15
GB
6.4 Battery capacity indicator (Fig. 6 – Item d)
Press the battery capacity indicator switch (e).
The battery capacity indicator (d) shows the char-
ge status of the battery using 3 LEDs.
All 3 LEDs are lit:
The battery is fully charged.
2 or 1 LED(s) are lit:
The battery has an adequate remaining charge.
1 LED fl ashes:
The battery is empty, recharge the battery.
All LEDs blink:
The battery temperature is too low. Remove the
battery from the equipment, keep it at room tem-
perature for one day. If the fault reoccurs, this me-
ans that the rechargeable battery has undergone
exhaustive discharge and is defective. Remove
the battery from the equipment. Never use or
charge a defective battery.
6.5 LED lamp (Fig. 1/Item 2)
The LED lamp (2) can be used in poor lighting
conditions to illuminate the area where you want
to screw. The LED light (2) will come on automati-
cally as soon as you press the On/Off switch (4).
6.6 Changing the plug-in tool (Fig. 7)
Important! Whenever you carry out any work on
the tool (e.g. changing the plug-in tool, mainte-
nance work, etc.), set the direction of rotation
switch (3) to lock position. (See 6.3)
Fitting / removing the plug-in tool
Fit the required drive socket insert by pushing
onto the square drive mount (1).
Remove the drive socket insert by pulling it off the
square drive mount (1).
6.7 Working with the cordless ratchet
screwdriver
Loosening:
•
Set the direction of rotation switch (5) to
counter-clockwise (L). (See 6.2)
•
Fit a drive socket insert on the tool. (See 6.6)
•
Place the tool on the screw/nut and press the
On/Off switch (4) to loosen the screw/nut.
•
If the screws/nuts are very tight or if they are
rusted, use a wheel spider or torque wrench
to slightly loosen them.
- 15 -
