Installation
3.4.6

Establish electrical power supply

☞ Observe the voltage specifications on the rating plate.
☞ Plug the connecting cable mains plug into the socket.
☞ Route the cable such that it is not kinked, crushed or
damaged and so that it will not get in the way when
replacing the filter filling.
☞ Make sure the device can be disconnected from the
electricity supply after installation.
6003417_a – 26.09.2017
All manuals and user guides at all-guides.com
☞ Connect the recirculated air filter permalyt as follows:
☞ Plug the cold device plug into the socket on the fan
A connection check takes place automatically:
y If the device is not connected correctly, five beeps will
y If the device is connected correctly, three will beeps
☞ Insert the recirculated air filter permalyt.
☞ Lay the cable from the recirculated air filter permalyt
3.4.7

Installing the recirculated air filter permalyt

y Wire 1 on terminal 1
y Wire 2 on terminal 2
housing.
sound.
☞ Correct the connection of the wires to terminals 1 and
2.
sound.
through the guide channel.
101
