Dometic FreshLight
Connecting the air outlet unit with the roof air conditioner
See fig. d
➤ Remove the premounted filter covers (1).
➤ Remove the premounted air filter (2).
Fitting the seals
See fig. e
➤ Fit the seals (1).
Determine the thickness by referring to the following table:
Ceiling thickness
25 mm
25 – 30 mm
30 – 35 mm
35 – 40 mm
40 – 45 mm
45 – 50 mm
50 – 55 mm
55 – 60 mm
Connecting the circuit board
See fig. f
➤ Insert the 12-pin plug (1) in the socket (4) on the circuit board of the air outlet unit.
➤ Insert the 2-pin plug (2) in the socket (3) on the circuit board.
EN
Seal thickness
20 mm
25 mm
30 mm
35 mm
40 mm
45 mm
50 mm
55 mm
Installation
15
