Mounting the antennas to the front of the rack
When rack mounting the receiver, you require the GA 3030 AM antenna
mount (available as an accessory) to mount the antenna connections to
the front of the rack. The GA 3030 AM antenna mount consists of:
2 BNC extension cables (screw-in BNC socket
2 antenna holders
4 screws
Y
2 washers
X
2 nuts
Unsecure the rack mount "ears"
Guide the BNC cables through the holes in the rack mount "ears" as
shown in the diagram on the left.
Screw the antenna holders
X
washers
and nuts
Secure the antenna holders
of the supplied screws respectively.
Connect the two BNC connectors
rear of the receiver.
Slide the receiver into the 19'' rack.
Resecure the rack mount "ears"
Connect the antennas
Align the antennas upwards in a V-shape.
Putting the receiver into operation
W
Z
1
from the rack.
Z
to the BNC sockets
W
.
Z
to the handles of the receiver using two
[
to the BNC sockets
1
to the rack.
\
W
to the BNC sockets
[
to BNC connector
)
Y
using the supplied
O
R
and
at the
.
15
