Charge-status and fault indicator (Li-ion
&
battery)
Release buttons (also used to activate
(
the charge status indicator)
Battery
)
Side handle
+
Intended use
The product described is a cordless (battery-powered) breaker with pneumatic hammering mecha-
nism. The product designed for light to medium chiseling work on masonry and surface finishing
work on concrete.
Use only Hilti Li-ion batteries from the B 36 series with this product.
Use only the Hilti battery chargers from the C4/36 series for these batteries.
Possible misuse
• This product is not suitable for working on hazardous materials.
• This product is not suitable for working in a damp environment.
Active Vibration Reduction
The tool is equipped with an Active Vibration Reduction (AVR) system which reduces vibration
noticeably.
Service indicator
The product is equipped with a service indicator LED.
MMI
Status
The Service indicator lights up.
The Service indicator flashes.
The ON/OFF indicator lights up.
The ON/OFF indicator flashes.
The ON/OFF indicator is off.
The Half power indicator lights up.
The Half power indicator is off.
Lithium­ion battery status display
The Li-ion battery state of charge and malfunctions of the power tool are indicated by the display on
the Li­ion battery. The Li­ion battery state of charge is displayed after pressing one of the two battery
release buttons.
Status
4 LEDs light.
3 LEDs light.
2 LEDs light.
1 LED lights.
1 LED blinks.
1 LED flashes, the product is not in working
order.
4 LEDs flash, the product is not in working or-
der.
19
On/off switch
§
Button for half power
/
Half-power indicator
:
Service indicator
ON/OFF indicator
$
Meaning
Servicing is due.
Have the product repaired by Hilti Service.
The product is switched on
The product is switched off because of a tran-
sient fault.
The product is switched off.
The product is working at half power.
The product is working at full power.
Meaning
State of charge: 75 % to 100 %
State of charge: 50 % to 75 %
State of charge: 25 % to 50 %
State of charge: 10 % to 25 %
State of charge: < 10 %
The battery has overheated or is completely
discharged.
The power tool is overloaded or has overheat-
ed.
